Major Specification
|
| NCPT-40 |
| Output |
Rod Side |
40㎥/hr |
52yd³/hr |
| Piston Side |
28㎥/hr |
36yd³/hr |
| Pressure |
Rod Side |
60bar |
870psi |
| Piston Side |
85bar |
1,232psi |
| Concrete Cylinder Diameter |
180mm |
7" |
| Stroke Length |
1,000mm |
3'28" |
| No.of Strokes / Min |
Rod Side |
27 |
| Piston Side |
19 |
| Hopper Capacity |
450L |
15.88ft³ |
| Volume Control |
|
| Hydraulic System |
Open-Circuit |
| Hydraulic System Pressure |
350bar |
5,075psi |
| Hydraulic Tank Capacity |
250L |
66gal |
| Water Pump Pressure |
20bar |
290psi |
| Outlet Diameter |
125mm |
5" |
| Max Size Aggregate |
63mm |
2.5" |
| Diesel Engine |
DEUTZ |
| Engine Horse Power |
85kw/115ps |
|
※The Specification can be changed without any prioi notice
|
